Prodcuts Features:
● It is convenient to be mounted and maintained.● It can be fitted with lamp shade.
● The degree of protection is up to IP66.
● IECEx, ATEX International certification
| Certification： |
China: CNEx14.0610 Ex mark: Ex nR II C T* Gc Ex tb IIIC T* Db
IECEx: IECEx CQM 13.0010X Ex mark:Ex nR II C T* Gc Ex tb IIIC T* Db
ATEX:TüV 14 ATEX 7582X TüV 14 ATEX 7581X
Ex mark: II 3 G Ex nR II C T* Gc II 2 D Ex tb IIIC T* Db |
| Intended use: | Can be used in zone 2 Can be used in zone 21 and zone 22 |
| Ambient temperature use: | -40°C to+40℃/+55°C |
| Degree of protection: | IP66 |
| Rated voltage： | 220V AC 50Hz 220V AC、230V AC、240V AC 50Hz、60Hz 120V/208V/240V/277V/480V AC 60Hz |
| Terminal: | L1, N terminal 2-2.5mm² , PE terminal: 2×10mm² |
| Cable entry： | A—Pendant pole type lamp (Standard configuration) 1×G3/4", outside diameter: Φ11-15mm B—Bracket type lamp (Standard configuration) Moulded plastic 1×M25×1.5, Outside diameter: Φ8-17mm Moulded plastic 1×M25×1.5 stopping plug C—Platform type lamp 90°(Standard configuration) D—Platform type la mp 25°(Standard configuration) Moulded plastic 1×M25×1.5, Outside diameter: Φ8-17mm E—Wall type lamp (Standard configuration) Moulded plastic 1×M25×1.5, Outside diameter: Φ8-17mm Moulded plastic 3×M25×1.5 stopping plug |
