Custom CZ0873/2BJD LED Explosion-proof warning light fittings Suppliers, Company

CZ0873/2BJD LED Explosion-proof warning light fittings

Prodcuts Features:

● The highest class of flameproof is up to IIC.
● The degree of protection is up to IP66.
● IECEx, ATEX International certification.

Product Parameter

Product type：	LED Explosion-proof warning light fittings
Certification：	CCC IECEX ATEX
Application range (zones)：	2G/Gb/zone 1；2D/Db/zone 21
Min.ambient temperature：	-40℃
Max.ambient temperature：	+55℃
Degree of protection：	IP66
Rated voltage：	24V AC/DC，110V AC 50/60Hz，220V AC 50/60Hz，220~240V AC 50/60Hz
Power：	Max 10W
Light source：	LED

Certification：	China: CNEx14.0611 Ex mark: Ex de II C T6 DIP A21 TA, T6 IECEx: IECEx CQM13.0025X Ex mark: Ex de II C T6 Gb Ex tb IIIC T80°C Db ATEX:TUV14 ATEX 7580X Ex mark: II 2 GD Ex de II C T6 Gb Ex tb IIIC T80°C Db
Intended use:	Can be used in zone 1 and zone 2 Can be used in zone 21 and zone 22
Ambient temperature use:	-20℃ to+40℃/+55℃ -40℃ to+40℃/+55℃
Degree of protection:	IP66
Rated voltage：	24V AC/DC 110V AC 50/60Hz 220V AC 50/60Hz 220~240V AC 50/60Hz
Power:	Max 10W
Light source：	LED
Terminal：	L1, N cage type terminal 2-2.5mm² , PE terminal: 2×10mm²
Cable entry：	Moulded plastic 1×M25×1.5, Outside diameter: Φ8-17mm Moulded plastic 1×M25×1.5 stopping plug

About CZ

CZ Electric Co., Ltd was established in 1990, is a CZ0873/2BJD LED Explosion-proof warning light fittings suppliers, and is headquartered in Jiaxing City, Zhejiang Province, CZ can provide users with comprehensive explosion-proof safety system solutions. Products are widely used in engineering projects such as petrochemicals, medical machinery, food processing, precision electronics, military ships, aerospace and aviation. The products are exported to 56 countries and regions such as the European Union, the Middle East, Southeast Asia, Russia, Japan, Australia. CZ has agents or offices in 28 countries and regions, and has participated in the construction of key projects: oil and gas pipeline projects in cooperation between China and Turkmenistan , PetroChina Fushun 10 million tons refinery 800,000 tons ethylene project, Kuwait National Petroleum HEAVY OILLONG TERM TESTING FACILITY (HOLTTF) project, Oman National Petroleum Corporation MABRUK PROJECT-PRRF project, Australia Ichthys liquefied natural gas (LNG) project and other projects and won praise from users.
