Custom CZ6474121H Explosion-proof light fittings（LED spot light） Suppliers, Company

CZ6474121H Explosion-proof light fittings（LED spot light）

Prodcuts Features:

● It is long life and maintenance-free which the service life is up to 50000 hours and the maintenance-free of long term.

● There is a feature of good electromagnetic compatibility and it does not cause interference to the system power grid.

● There is a good performance of vibration due to the LED is the solid-state light source.

● The highest flameproof level is IIC.

● It is convenient to be mounted and maintained.

● The degree of protection is up to IP66.

● International IECEx Approval, Europe union ATEX Approval.

Product Parameter

Product type:	Explosion-proof light fittings（LED spot light）
Certification:	China IECEX ATEX
Application range (zones):	2G/Gb/zone 1；2D/Db/zone 21
Min.ambient temperature:	T6：-60℃/ -40℃
Max.ambient temperature:	T6：+40℃ T5：+55℃
Degree of protection:	IP66
Rated voltage:	20 ～ 40V DC/20 ~ 40V AC 50/60Hz 127～ 250V DC/100 ～ 250V AC 50/60Hz
Color temperature:	Standard 5000K,（Optional 3000K,4000K,6500K）
Material of enclosure:	Aluminum alloy / tempered glass (transparent lampshade）

Certification：	China:Ex db IIC T6/T5 Gb Ex tb IIIC T80°C/T95°C Db IECEx: Ex db IIC T6/T5 Gb Ex tb IIIC T80°C/T95°C Db ATEX: II 2GD Ex db IIC T6/T5 Gb Ex tb IIIC T80°C/T95°C Db
Intended use:	Can be used in zone 1 and zone 2 Can be used in zone 21 and zone 22
Ambient temperature use:	-60℃/-40℃≤Ta≤+40℃/55℃ （-60°C lamp electrical equipment need to be customized）
Degree of protection:	IP66
Rated voltage：	20 ～ 40V DC/20 ~ 40V AC 50/60Hz 127～ 250V DC/100 ～ 250V AC 50/60Hz
Color temperature:	Standard 5000K, （Optional 3000K,4000K,6500K）
Power factor:	λ＞0.98
Terminals:	Terminal 2.5mm² , PE terminal: 2×10mm²
Cable entry:	DC1: 1-M25, oustide diameter: Φ12-19mm（CZ1725/1C） 1-M25, stopping plug（CZ1725/3A） DC0: 1-M25, oustide diameter: Φ12-19mm（CZ1725/1C）
