Custom CZ1220e Full plastic Explosion-proof Terminal Boxes (cable end box) Suppliers, Company

CZ1220e Full plastic Explosion-proof Terminal Boxes (cable end box)

Prodcuts Features:

● Combined enclosure.
● Wiring from various directions.
● Metal cable glands may be selected.
● IECEx International Approval, ATEX European union certification.

Product Parameter

Product type:	Full plastic Explosion-proof Terminal Boxes (cable end box)
Certification:	CCC IECEX ATEX
Application range (zones):	2G/Gb/zone 1；2D/Db/zone 21
Min.ambient temperature:	-55℃
Max.ambient temperature:	+55℃
Degree of protection:	IP66/IP65
Rated current:	Copper bar;250A ( 5×20mm ) 400A ( 10×20mm ) 630A ( 15×20mm )
Clamping range of line pressing terminals:	35 ～ 70mm², 35 ～ 240mm², 35 ～ 300mm²
High current terminal:	50 ～ 240mm²
Material of enclosure:	GRP(anti-static glass fibre reinforced polyester SMC)

Certification：	China: CE 18.5062X Ex mark: Ex eb ⅡC T6/T5/T4 Gb Ex tD A21 IP66 T80℃/T95℃/T130℃ IECEx: IECEx CML 17.0044X Ex mark: Ex eb ⅡC T6/T5/T4 Gb Ex tb ⅢC T80℃/T95℃/T130℃ Db ATEX: CML 17ATEX3104X Ex mark: Ⅱ2G Ex eb ⅡC T6/T5/T4 Gb Ex tb ⅢC T80℃/T95℃/T130℃ Db
Intended use:	Can be used in zone 0,zone 1 and zone 2 Can be used in zone 20，zone 21 and zone 22
Ambient temperature:	-40℃≤Ta≤+40℃/+55℃ -55℃≤Ta≤+40℃/+55℃
Degree of protection:	IP66/IP65
Rated current:	Copper bar: 250A ( 5×20mm ) 400A ( 10×20mm ) 630A ( 15×20mm )
Clamping range of line pressing terminals：	35 ~ 70mm² 35 ~ 240mm² 、35 ~ 300mm²
High current terminal：	50 ~ 240mm²
Material of enclosure:	GRP (anti-static glass fibre reinforced polyester SMC)
