Product type： |
LED Explosion-proof light fittings |
|
Certification： |
CCC IECEX ATEX |
|
Application range (zones)： |
3G/Gc/zone 2；2D/Db/zone 21 |
|
Min.ambient temperature： |
-40℃ |
|
Max.ambient temperature： |
+55℃ |
|
Degree of protection： |
IP66 |
|
Rated voltage： |
100 ~ 240V AC 50/60Hz |
| Certification： | China: CNEx 17.2163X Ex mark:Ex nR II C T5/T4 Gc Ex tD A21 IP66 T95°C/T130°C IECEx: IECEx CNEX 17.0005X Ex mark: Ex nR II C T5/T4 Gc Ex tb op is IIIC T95°C/T130°C Db ATEX: CNEx 16 ATEX 0011X Ex mark: II 3G2D Ex nR II C T5/T4 Gc Ex tb op is IIIC T95°C/T130°C Db |
| Intended use: | Can be used in zone 2 Can be used in zone 21 and zone 22 |
| Ambient temperature use: | -40℃≤Ta≤+40℃/+55℃ |
| Degree of protection: | IP66 |
| Rated voltage： | 110V~250V AC 50/60Hz |
| Light source： | LED |
| Colour temperature： | 5700K |
| Power factor： | ≥0.95 |
| Terminal： | L1, N terminal 2-2.5mm² , PE terminal: 2×10mm² |
| Cable entry： | B—Bracket type lamp (Standard configuration) Moulded plastic 1×M25×1.5, Outside diameter: Φ8-17mm Moulded plastic 1×M25×1.5 stopping plug C—Platform type lamp 90°(Standard configuration) D—Platform type la mp 25°(Standard configuration) F—Street lamp(Standard configuration) Moulded plastic 1×M25×1.5, Outside diameter: Φ8-17mm E—Wall type lamp (Standard configuration) Moulded plastic 1×M25×1.5, Outside diameter: Φ8-17mm Moulded plastic 3×M25×1.5 stopping plug |
 D0879/2
|
Mounting bracket Accessories for bracket type lamp |
 D8725
|
Lamp pole of fence type Accessories for platform type lamp, G1 1/2 " galvanized steel pipe material and powder coated surface |
 D8726
|
Accessories for platform type lamp, G1 1/2 " galvanized steel pipe material and powder coated surface |
 AH,BH,CH
|
AH:Lamp pole of single arm BH:Lamp pole of double arms with equal length CH:Lamp pole of double arms with non-equal length |
 CZ0930
|
Code：10,11 Single lamp equipped with one fuse code：20,21 Double lamps equipped with two fuses |
 D8722/3
|
Ceiling bracket |
 D732
|
G3/4"-300 Straight pipe Accessories for bracket type, galvanized steel pipe material and powder coated surface |
 D623
|
500mm Chain type accessories Accessories for bracket type lamp, M8 bolt, made from steel with zinc-coated surface |
