MS0253 Industrial plugs and sockets(switchgear with mechanical interlock)

Prodcuts Features:

● Self-cleaning inserting sleeve, low transmission resistance.
● Protective covers ensure high degree of protection.
● Small force of inserting and pulling.
● The wiring space is large enough .
● CCC, CE certification.

Product Parameter

Product type：	Industrial plugs and sockets(switchgear with mechanical interlock)
Certification：	CCC CE
Corrosion-proof mark：	WF2
Min.ambient temperature：	-55℃
Max.ambient temperature：	+55℃
Degree of protection：	IP66
Rated voltage：	4 poles — max 690V AC 50/60Hz 5 poles — max 415V AC 50/60Hz
Rated current：	63A
Material of enclosure：	glass fibre reinforced polyester SMC polyamide

Certification：	China Ex mark: CCC European Union Ex mark:CE
Corrosion-proof mark：	WF2
Degree of protection：	IP66
Ambient temperature：	-55℃≤Ta≤+55℃
Rated current：	63A
Rated voltage：	4 poles — max 690V AC 50/60Hz 5 poles — max 415V AC 50/60Hz
Rated switch capacity：	AC-3 690V/63A
Aux. switch：	AC250V/5A
Terminals:	2×16mm² ( wall type socket ) 1×16mm² ( plug )
Aux. contact of wall type socket：	2×2.5/4mm²
Cable entry：	Wall type socket ( standard configure ) Moulded plastic 1×M50×1.5 (cable outside diameter Φ22 ~ 35mm) Moulded plastic 1×M50×1.5 stopping plug Other certified cable glands can be used Plug: 4 poles, 5 poles ( cable outside diameter Φ15~ 35mm )
Material of enclosure:	glass fibre reinforced polyester SMC polyamide
