CZ-ZFJC-CZ6474 Explosion-proof centrally power supply and control type fire emergency lighting luminaire

Prodcuts Features:

● Safe and reliable voltage DC 36V as power supply.

● It is long life and maintenance-free which the service life is up to 50000 hours.

● There is a feature of good electromagnetic compatibility and it does not cause interference to the system power grid.

● There is a good performance of vibration due to the LED is the solid-state light source.

● The highest flameproof calss of is up to IIC.

● It is convenient to be mounted and maintained.

● The degree of protection is up to IP66.

● Fire certinfication.

Product Parameter

Product type:	Explosion-proof centrally power supply and control type fire emergency lighting luminaire
Certification:	CCCF
Application range (zones):	Can be used in zone 1 and zone 2 Can be used in zone 21 and zone 22
Min.ambient temperature:	-60°（-60°C lamp electrical equipment need to be customized）
Max.ambient temperature:	+55℃
Degree of protection:	IP66
Rated voltage:	36V DC

Certification：	China: CE17.5005X Ex mark: Ex d e mb q IIC T5/T4 Gb Ex tD A21 IP66 T80°C IECEx: IECEx CML 16.0116X Ex mark:Ex db eb mb op is q IIC T5/T4 Gb Ex tb op is IIIC T80°C Db ATEX: CML 16ATEX1342X Ex mark: II 2 G D Ex db eb mb op is q IIC T5/T4 Gb Ex tb op is IIIC T80°C Db
Intended use:	Can be used in zone 1 and zone 2 Can be used in zone 21 and zone 22
Ambient temperature :	-40℃≤Ta≤+40℃/55℃ -60℃≤Ta≤+40℃/55℃ （-60°C lamp electrical equipment need to be customized）
Degree of protection:	IP66
Rated voltage:	36V DC
Emergency type:	Non-maintained
Power supply type:	Centrally power supply
Control type:	Centrally control
Emergency starting time:	≤0.25S
Emergency illuminating time：	90min
Terminals:	2×2.5mm², PE terminal: 2×10mm²
Cable entry:	2-M25×1.5
Weight:	1.83kg
